Integrates solar, wind power, diesel generators, and energy storage systems to achieve an energy-saving solution, with a maximum load capacity of up to 600A
The cabinet is made of lightweight aluminum alloy, allowing for manual transportation. It supports factory prefabrication and can be lifted and installed as a whole unit
The outer layer of the cabinet is made of corrosion-resistant FRP material, making it suitable for coastal environments
Combines power generation, energy storage, and communication infrastructure in a single system, enabling rapid and efficient deployment
| Container Product Specifications | Overall dimensions (width x length x height) | 2400mm(W)×6000mm(L)×2800mm(H) IP55 protection; |
| Installation Mode | Landing | |
| Cooling Solution | Intelligent temperature control (Fresh air system / precision air conditioning, energy-saving automatic switching refrigeration） | |
| AC Input | AC input voltage | Single-phase/three-phase 380VAC input (dual input interlock) |
| Rectifier module | 50A, fully equipped 600A Shared slot with photovoltaic modules | |
| Photovoltaic input | Photovoltaic module capacity | 550Wp*12 pieces;=6.6kw |
| Photovoltaic modules | 50A(3000W)*4 | |
| Wind power | Wind power | 600W~2000W |
| Fan control module | 2KW | |
| Energy storage and backup | Lithium iron phosphate battery | 100AH, 51.2V; fully equipped with 4 groups,Energy storage 50KWH |
| Output Characteristics | DC output voltage | 432VDC~58VDC (default 535VDC) |
| Output Configuration | Battery: 2*600A DC: 63A*6, 32A*4, 16A*6; AC: input 32A*4, lightning protection level C; socket: 2-way; | |
| Monitoring unit system | Signal input | analog input (battery temperature) 4 digital dry contact inputs |
| Alarm output | 4-way dry contact | |
| Communication interface | RS485 | |
| Storage capacity | Up to 1000 historical alarm records | |
| Sensor | Temperature and humidity, smoke, access control, water immersion | |
| Environment | Operating temperature | -20~+75℃(can be started at -40℃) |
| Storage temperature | -40℃~+75℃ | |
| Operating humidity | 5%~95%(no condensation) | |
| Altitude | ≤4000m (1800m~4000m, the temperature decreases by 1ºC for every 200m increase in altitude.) |
| Serial number | Name | Parameter Description | Quantity | Unit |
| 1 | Container site | 5950*2500*2890 (length*width*height), container 20 feet, six-sided PU thermal insulation layer, electrostatic floor laid inside, sufficient for 6 rack positions; | 1 | Tower |
| Serial number | Name | Parameter Description | Quantity | Unit |
| 1 | Container site | 5950*2500*2890 (length*width*height), container 20 feet, six-sided PU thermal insulation layer, electrostatic floor laid inside, sufficient for 6 rack positions; | 1 | Tower |
| 2 | Air conditioner | 3P energy-saving air conditioner, AC input 220V/380V, cabinet base station air conditioner, with power start, communication 485 interface; | 1 | Set |
| Serial number | Name | Parameter Description | Quantity | Unit |
| 1 | Container site | 5950*2500*2890 (length*width*height), container 20 feet, six-sided PU thermal insulation layer, electrostatic floor laid inside, sufficient for 6 rack positions; | 1 | Tower |
| 2 | Hybrid power supply box 600A (including AC power distribution box) | 6U, rack-mounted, AC input: 100A/3P*2 with interlocking device; AC lightning protection: Class C 30KA-60KA; AC output 63A/2P**2, 16A/1P*3, national standard socket*2; DC Output power distribution: 63A*4, 32A*4*16A*4; equipped with intelligent circuit breaker*3 channels, battery circuit breaker 125A*6; | 1 | Set |
| 3 | Rectifier module | Rectifier module 50A, high efficiency | 4 | Set |
| 4 | Air conditioner | 3P energy-saving air conditioner, AC input 220V/380V, cabinet base station air conditioner, with power start, communication 485 interface; | 1 | Set |
| Serial number | Name | Parameter Description | Quantity | Unit |
| 1 | Container site | 5950*2500*2890 (length*width*height), container 20 feet, six-sided PU thermal insulation layer, electrostatic floor laid inside, sufficient for 6 rack positions; | 1 | Tower |
| 2 | Photovoltaic panel | Single crystal panel complete set 550W, including adapter and installation accessories | 8 | Set |
| 3 | Photovoltaic module | Photovoltaic module 50A, MPPT efficiency: ≥99% | 2 | Set |
| 4 | Air conditioner | 3P energy-saving air conditioner, AC input 220V/380V, cabinet base station air conditioner, with power start, communication 485 interface; | 1 | Set |
| Serial number | Name | Parameter Description | Quantity | Unit |
| 1 | Container site | 5950*2500*2890 (length*width*height), container 20 feet, six-sided PU thermal insulation layer, electrostatic floor laid inside, sufficient for 6 rack positions; | 1 | Tower |
| 2 | Dynamic environment monitoring unit | 4 RS485 serial ports, 4 DI inputs, and 4 DO dry contact outputs. The software has a web management interface. The collector can be configured through a web browser. It supports access to the background monitoring system for centralized monitoring through SNMP or B interface. Environmental detection: smoke detector, access control, temperature and humidity, water immersion, etc. | 1 | Set |
| 3 | Sensor | Environmental detection: smoke sensor, access control, temperature and humidity, water immersion, need to be applied to monitoring; | 1 | Set |
| 4 | Fire extinguisher | Suspended 6kg temperature-controlled gas fire extinguishing device machine room gas fire extinguisher, heptafluoropropane | 1 | Set |
| 5 | Hybrid power supply box 600A (including AC power distribution box) | 6U, rack-mounted, AC input: 100A/3P*2 with interlocking device; AC lightning protection: Class C 30KA-60KA; AC output 63A/2P**2, 16A/1P*3, national standard socket*2; DC Output power distribution: 63A*4, 32A*4*16A*4; equipped with intelligent circuit breaker*3 channels, battery circuit breaker 125A*6; | 1 | Set |
| 6 | Rectifier module | Rectifier module 50A, high efficiency | 4 | Set |
| 7 | Photovoltaic panel | Single crystal panel complete set 550W, including adapter and installation accessories | 8 | Set |
| 8 | Photovoltaic module | Photovoltaic module 50A, MPPT efficiency: ≥99% | 2 | Set |
| 9 | Air conditioner | 3P energy-saving air conditioner, AC input 220V/380V, cabinet base station air conditioner, with power start, communication 485 interface; | 1 | Set |
| Serial number | Name | Parameter Description | Quantity | Unit |
| 1 | Container site | 5950*2500*2890 (length*width*height), container 20 feet, six-sided PU thermal insulation layer, electrostatic floor laid inside, sufficient for 6 rack positions; | 1 | Tower |
| 2 | Dynamic environment monitoring unit | 4 RS485 serial ports, 4 DI inputs, and 4 DO dry contact outputs. The software has a web management interface. The collector can be configured through a web browser. It supports access to the background monitoring system for centralized monitoring through SNMP or B interface. Environmental detection: smoke detector, access control, temperature and humidity, water immersion, etc.; | 1 | Set |
| 3 | Sensor | Environmental detection: smoke sensor, access control, temperature and humidity, water immersion, need to be applied to monitoring; | 1 | Set |
| 4 | Fire extinguisher | Suspended 6kg temperature-controlled gas fire extinguishing device machine room gas fire extinguisher, heptafluoropropane | 1 | Set |
| 5 | Hybrid power supply box 600A (including AC power distribution box) | 6U, rack-mounted, AC input: 100A/3P*2 with interlocking device; AC lightning protection: Class C 30KA-60KA; AC output 63A/2P**2, 16A/1P*3, national standard socket*2; DC Output power distribution: 63A*4, 32A*4*16A*4; equipped with intelligent circuit breaker*3 channels, battery circuit breaker 125A*6; | 1 | Set |
| 6 | Rectifier module | Rectifier module 50A, high efficiency | 4 | Set |
| 7 | Lithium iron phosphate battery | 100AH, rack-mounted -48V, more than 3000 charging cycles, 16S | 8 | Set |
| 8 | Photovoltaic panel | Single crystal panel complete set 550W, including adapter and installation accessories | 8 | Set |
| 9 | Photovoltaic module | Photovoltaic module 50A, MPPT efficiency: ≥99% | 2 | Set |
| 10 | Air conditioner | 3P energy-saving air conditioner, AC input 220V/380V, cabinet base station air conditioner, with power start, communication 485 interface; | 1 | Set |
Note: Specifications are subject to change without prior notice for product improvement. Data Sheet
Telecom Networks: Ideal for powering medium- to large-scale telecom stations in off-grid areas.
Other Applications: Suitable for communication base stations, smart cities, transportation, and power systems, providing stable backup power and optical fiber connectivity in edge site scenarios.
