Wall-mounted structure that efficiently utilizes space, ideal for indoor installation
Advanced energy management ensures optimal charge and discharge performance
Seamless integration with solar panels and grid systems, offering off-grid, grid-tied, and hybrid configurations
Multi-level safety protections including overcharge, over-discharge, and temperature controls
| Product Number | HJ-HBL48100W | HJ-HBL48200W |
| Battery Type | Lithium Iron Phosphate Battery | |
| Battery Power | 5.12kWh | 10.24kWh |
| Battery Capacity | 100Ah | 200Ah |
| Rated Voltage | 51.2Vdc | |
| Rated Charge and Discharge Current | 50A | 100A |
| Maximum Charge and Discharge Current | 100A | 200A |
| Cycle Life | > 6000 times @80%DOD@25°C | |
| Way of Communication | RS485/CAN | |
| Display Screen | LCD/LED (optional) | |
| Degree of Protection | IP65 | |
| Item | Specifications and models | Unit | Quantity |
| Battery system | Including 1 set of battery PACK, BMS system, more than 3000 cycles | SET | 1 |
| Photovoltaic storage inverter | Hybrid type, 1) Photovoltaic input power: ≥5KW and photovoltaic voltage 125V~500V, with MPPT; 2) AC voltage: 230V, frequency 50HZ/60HZ, output power 5KW; 3) Battery voltage: 48V 4) With LCD/LED display, with communication RS485; |
PCS | 1 |
| WIFI module, matching the optical storage integrated inverter for use | PCS | 1 | |
| Power distribution system | / | SET | 1 |
| Accessories in the cabinet | / | SET | 1 |
| Solar panel | 550W, monocrystalline silicon, single plane, N type | PIECE | 6 |
| Solar panel bracket | Suitable for the use of solar photovoltaic panels, the photovoltaic bracket is installed in the inclined roof | SET | 6 |
| Direct current cable | PV1-F 1*4mm²RED | M | 12 |
| Direct current cable | PV1-F 1*4mm²BLACK | M | 12 |
| Ground lead | 6mm²Yellow green ground line | M | 5 |
| Junctor | MC4 male and female Junctors, including male and female Junctor pins. | SET | 2 |
| Wooden packaging | / | SET | 1 |
Note: Specifications are subject to change without prior notice for product improvement. Data Sheet
